New Upgraded MPPT Solar Charge Controller 12v/24v Solar Panel Regulator Auto Focus Tracking 20A blue

About this item

• Label: Yes Feature: 1. Built-in industrial microcontroller. 2. Large LCD display, system control parameters are all adjustable. 3. Full 4-level PWM charging management. 4. Built-in short circuit protection, open circuit protection, reverse protection, overload protection and all necessary protections. 5. Double mosfet reverse current protection, low heat generation LCD display/keys and operation: MENU: Switch between different displays, or long press to enter/exit settings. UP: Press to increase the value. DOWN: Press this key to decrease the value. System connection: 1. Connect the battery to the charge regulator-positive and negative. 2. Connect the photovoltaic module to the regulator-plus and minus. 3. Connect the consumer to the charging regulator-positive and negative. *The order is reversed when uninstalling! *Incorrect may damage the controller! Attention: 1. Press the [Down] key on the main display to manually turn on/off the load. 2. The working mode is as follows: [24H] Load output for 24 hours [1-23H] Load after sunset, close after set time [0H] Dusk to dawn 3. Battery: only applicable to OPEN, AGM, GEL 4. The charging regulator is only suitable for regulating solar components, do not connect other charging power sources to the charging regulator. 5. Before installing for the first time, please make sure that your battery has enough voltage for the controller to recognize the battery type. Specification: Load: light control MPN: RBL Charging method: PWM Model: RBL-60A System voltage: 12V 24V Maximum solar input (solar panel): 36V (24V battery) 18V (12V battery) Maximum input power: 650W (12V system); 1300W (24V system) Balance: 12.6V (sealed) 14.2V (gel) 14.6V (overflow) Floating charge: 13.7V (default, adjustable), 12.0-15.0V Discharge stop voltage: 10.7V (default, adjustable), 9.0-11.5V Discharge reconnection voltage: 12.5V (default, adjustable), 11.0-13.0V Rated current: 100A Self-consumption: <10mA Battery: only applicable to OPEN, AGM, GEL Working temperature: -35℃ 60℃ USB output: 5V/2A Max Size: 13.4*7*3.3cm Package includes: 30A solar charge controller*1
