31ZY Permanent Magnetic DC Carbon Brush Motor CWCCW (24V 8000rpm)

About this item

• Features: It adopts precision machining, magnetic material treatment, and insulation treatment, features stable and reliable. This DC motor features large moment of force, and low noise, Stable performance The motor is made of metal gear, wearresisting, avoid tooth breaking, so with long serving life. This DC motor supports clockwise and counterclockwise rotation. This motor is adopted of pure copper wire coil, with low heat and low loss. Specifications: Model: 31ZY Outer diameter: 31mm 1.22in Shaft length: 19mm 0.75in Shaft diameter: 3mm 0.12in Type(Optional) : 6V 4000rpm,12V 4000rpm,12V 8000rpm, 24V 3500rpm, 24V 5000rpm, 24V 8000rpm Weight:165g Wiring: CW: red: + , black: CWW: red: , black: + Working voltage V (Optional) 6V 12V 12V 24V 24V 24V Noload current mA less than 180 less than 350 less than 110 less than 200 less than 200 less than 41 Noload speed rpm 4000 8000 4000 5000 8000 3500 Rated moment of force gf.cm 100 200 100 200 200 150 Rated speed rpm 3200 6500 3200 4000 6600 2500 Rated current A less than 0.8 less than 1.6 less than 0.5 less than 0.6 less than 1.0 less than 0.3 Lockedrotor moment of force gf.cm more than 500 more than 1000 more than 600 more than 850 more than 1200 less than 400 Lockedrotor current A less than 3.3 less than 6.5 less than 2.3 less than 2.0 less than 4.4 less than 0.8 Package includes: 1 x Motor It adopts precision machining, magnetic material treatment, and insulation treatment, features stable and reliable. This DC motor features large moment of force, and low noise, Stable performance The motor is made of metal gear, wearresisting, avoid tooth breaking, so with long serving life. This DC motor supports clockwise and counterclockwise rotation. This motor is adopted of pure copper wire coil, with low heat and low loss.
