Pressure Transducer Sender Sensor Stainless Steel for Oil Fuel Air Water (100PSI)

About this item

• Features: It s an advance pressure transducer than traditional mechanical pressure transducer. +2percent FS small output error, including nonlinear, hysteresis error and repeatability, full temperature range. Light weight and small size, convenient to install and operate. Works for oil, fuel, diesel, gas, water, air pressure, can be used in oil tank, gas tank, diesel tank etc. Specifications: Material: Stainless steel Thread Type: 18 NPT 30 psi Input: 030 psi Accuracy: within 2percent of reading (full scale). Thread: 18 27 NPT. Wiring Connector: Water sealed quick disconnect. Mating connector is included. Wiring: Red for +5V; Black for ground; Blue for signal output. 100 psi Input: 0100 psi Accuracy: within 2percent of reading (full scale). Thread: 18 27 NPT Wiring Connector: Water sealed quick disconnect. Mating connector and wire harness (pigtail) is included. Wiring: Red for +5V; Black for ground; Blue for signal output. 150 psi Input: 0150 psi Accuracy: +0.5percent FS Thread: 18 NPT Wiring: Red for +5V; Black for ground; Green for signal output Overload Capacity: 24 times of rated pressure Working Temperature: 40 celsius ~+120 celsius Compensation Temperature: 0 celsius ~+80 celsius Protection Class: IP67 Pressure Medium: Oil, gas and water which is compatible with 316L stainless steel Load Resistance: less than (supply power6.5V0.02A) Ohm Longterm Stability: Less than 0.1percent FSyear Temperature Effect on Zero: Typical:0.02percent FS celsius ; Maximum:0.05percent FS celsius Temperature Effect on Sensitivity: Typical: 0.02percent FS celsius ; Maximum: 0.05percent FS celsius Shock Resistance: 1000g AntiShock: less than +0.01percent FS(X,Y,Z axes, 200Hzg) Response Time: less than 1ms Insulation Resistance: >100m Ohm 500VDC Explosionproof Class: ExiaTTCT6 Electromagnetism Compatibility: EN500511 200 psi Input: 0200 psi Working Temperature: 40~+125 celsius Accuracy: +1percent FS Thread: 18 27 NPT Overload Capacity: 2 times of rated pressure Pressure Medium: Oil, gas and water which is compatible with 316L stainless steel Load Resistance: less than (supply power6.5V0.02A) Ohm Longterm Stability: + 0.2percent FSyear Temperature Effect on Zero: Typical: +0.02percent FS celsius ; Maximum: +0.05percent FS celsius Temperature Effect on Sensitivity: Typical: +0.02percent FS celsius ; Maximum: +0.05percent FS celsius Shock Resistance: 100g AntiShock: less than +0.01percent FS(X,Y,Z axes, 200Hzg) Response Time: less than 1ms Insulation Resistance: >100m Ohm 500VDC Explosionproof Class: ExiaTTCT6 Electromagnetism Compatibility: EN500811; EN500822; IEC6 100043 Wiring Connector: Water sealed quick disconnect. Mating connector and wire harness (pigtail) is included. Wiring: Red for IN+; Black for GND; Green for OUT. 300 psi Input: 0300 psi Accuracy: +0.5percent FS Thread: 18 NPT Wiring: Red: +5V; Black: ground; Green: signal output Overload Capacity: 24 times of rated pressure Working Temperature: 40~+120 celsius Compensation Temperature: 0 celsius ~+80 celsius Protection Class: IP67 Pressure Medium: Oil, gas and water which is compatible with 316L stainless steel Load Resistance: less than (supply power6.5V0.02A) Ohm Longterm stability: Less than 0.1percent FSyear Temperature Effect on Zero: Typical: 0.02percent FS celsius ; Maximum: 0.05percent FS celsius Temperature Effect on Sensitivity: Typical:0.02percent FS celsius ; Maximum:0.05percent FS celsius Shock Resistance: 1000g AntiShock: less than +0.01percent FS(X,Y,Z axes, 200Hzg) Response Time: less than 1ms Insulation Resistance: >100m Ohm 500VDC Explosionproof Class: ExiaTTCT6 Electromagnetism Compatibility: EN500511. 500 psi Input: 0500 psi (Gauge Pressure) Accuracy: +1percent FS Thread: 18 NPT Wiring: Red for +5V; Black for ground; Yellow (Green) for signal output Overload Capacity: 24 times of rated pressure Working Temperature: 40 celsius ~+120 celsius Compensation Temperature: 0 celsius ~+80 celsius Protection Class: IP67 Pressure Medium: Oil, gas and water which is compatible with 316L stainless steel Load Resistance: less than (supply power6.5V0.02A) Ohm Longterm stability: Less than 0.1percent FSyear Temperature Effect on Zero: Typical: 0.02percent FS celsius ; Maximum: 0.05percent FS celsius Temperature Effect on Sensitivity: Typical: 0.02percent FS celsius ; Maximum:0.05percent FS celsius Shock Resistance: 1000g AntiShock: less than +0.01percent FS(X,Y,Z axes, 200Hzg) Response Time: less than 1ms Insulation Resistance: >100m Ohm 500VDC Explosionproof Class: ExiaTTCT6 Electromagnetism Compatibility: EN500511. Package Includes: 1 x Pressure Transducer (With cable) .It s an advance pressure transducer than traditional mechanical pressure transducer +2percent FS small output error, including nonlinear, hysteresis error and repeatability, full temperature range Light weight and small size, convenient to install and operate It has complete surge voltage protection function Works for oil, fuel, diesel, gas, water, air pressure, can be used in oil tank, gas tank, diesel tank etc
